EML30US05-P
RoHS
RoHS compliant
RoHS compliantPackage 4-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description
XP POWER EML30US05-PAC/DC PCB Mount Power Supply, Medical, Adjustable, Fixed, 85 V, 264 V, 30 W, 5 V, 6 A
PDF
/
Buying Options
Total Price: USD $46.2
Unit Price: USD $46.2
≥1 USD $46.2
≥10 USD $43.58491
≥100 USD $41.11784
≥500 USD $38.79041
≥1000 USD $36.59473
≥3000 USD $34.52333
Inventory: 48
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 26.7mm
Technical
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 85V
Load Regulation ±1%
Line Regulation ±0.5%
Nominal Output Voltage 5V
Max Output Power 30W
Current - Output 1 6A
Max Input Voltage 264V
Min Input Voltage 85V
Output Power 30W
Voltage - Input 85V~264VAC
Max Output Current 6A
Efficiency 75%
Approval Agency CB, TUV, UL
Number of Outputs 1
Depth 75.2mm
Max Power Dissipation 30W
Applications Medical
Type Open Frame
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature OCP, OVP, SCP
Size / Dimension 2.96Lx1.36W x 1.05 H 75.2mmx34.6mmx26.7mm
Series EML30 (30W)
Published 2012
Operating Temperature -20°C~70°C With Derating
Physical
Weight 0.13lb 58.97g
Package / Case 4-DIP Module
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 17 Weeks
