EML15US36-P

XP Power
RoHS
RoHS RoHS compliant
Package 4-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description XP POWER EML15US36-PAC/DC PCB Mount Power Supply, Medical, Adjustable, Fixed, 85 V, 264 V, 15 W, 36 V, 420 mA
PDF
/
Buying Options
Total Price: USD $43.99
Unit Price: USD $43.99
≥1 USD $43.99
≥10 USD $41.5
Inventory: 5391
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Length 62mm
Height 24.1mm

Technical

Max Input Voltage (AC) 264V
Min Input Voltage (AC) 85V
Load Regulation ±1%
Line Regulation ±0.5%
Nominal Output Voltage 36V
Max Output Power 15W
Current - Output 1 420mA
Max Input Voltage 264V
Min Input Voltage 85V
Output Power 15W
Voltage - Input 85V~264VAC
Trim/Adjustable Output YES
Input Voltage-Nom 115V
Max Output Current 420mA
Output Voltage 36V
Efficiency 82%
Approval Agency CE, cULus, TUV
Number of Outputs 1
JESD-30 Code R-XDMA-P5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 30.7mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 15W
Applications Medical
Type Open Frame
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature OCP, OVP, SCP
Size / Dimension 2.44Lx1.21W x 0.96 H 62.0mmx30.7mmx24.4mm
Series EML15 (15W)
Published 2014
Operating Temperature -20°C~70°C With Derating

Physical

Weight 0.07lb 31.75g
Package / Case 4-DIP Module
Mounting Type Through Hole
Mount PCB, Through Hole

Supply Chain

Factory Lead Time 17 Weeks
