EML15US12-E image
Favorite
EML15US12-E image
Favorite

EML15US12-E

XP Power
RoHS
RoHS RoHS compliant
Package 4-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description XP POWER EML15US12-EAC/DC PCB Mount Power Supply, Medical, Fixed, 85 V, 264 V, 15 W, 12 V, 1.25 A
PDF
/
Buying Options
Total Price: USD $45
Unit Price: USD $45
≥1 USD $45
≥10 USD $42.45283
≥100 USD $40.04984
Inventory: 2434
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Length 65mm
Height 24.4mm

Technical

Max Input Voltage (AC) 264V
Min Input Voltage (AC) 85V
Load Regulation ±1%
Line Regulation ±0.5%
Nominal Output Voltage 12V
Max Output Power 15W
Current - Output 1 1.25A
Max Input Voltage 264V
Min Input Voltage 85V
Output Power 15W
Voltage - Input 85V~264VAC
Trim/Adjustable Output NO
Input Voltage-Nom 115V
Max Output Current 1.25A
Output Voltage 12V
Efficiency 80%
Approval Agency CE, cULus, TUV
Number of Outputs 1
JESD-30 Code R-XDMA-P4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 33.3mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 15W
Applications Medical
Type Enclosed
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature OCP, OVP, SCP
Size / Dimension 2.56Lx1.31W x 0.96 H 65.0mmx33.3mmx24.4mm
Series EML15 (15W)
Published 2014
Operating Temperature -20°C~70°C With Derating

Physical

Weight 0.2lb 90.72g
Package / Case 4-DIP Module
Mounting Type Through Hole
Mount PCB, Through Hole

Supply Chain

Factory Lead Time 17 Weeks
