EML15US09-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
XP POWER EML15US09-SAC/DC Enclosed Power Supply, Medical, Adjustable, Fixed, 85 V, 264 V, 15 W, 9 V, 1.67 A
PDF
/
Buying Options
Total Price: USD $52.25
Unit Price: USD $52.2474
≥1 USD $52.2474
≥10 USD $49.29
≥100 USD $46.5
≥500 USD $43.86792
≥1000 USD $41.38483
Inventory: 2224
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 26.416mm
Technical
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 85V
Nominal Output Voltage 9V
Minimum Load Required No
Max Output Power 15W
Current - Output 1 1.67A
Max Input Voltage 264V
Min Input Voltage 85V
Output Power 15W
Voltage - Input 85V~264VAC
Max Output Current 1.67A
Voltage - Isolation 4kV
Efficiency 80%
Number of Outputs 1
Max Power Dissipation 15W
Applications Medical
Type Open Frame
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Adjustable Output, DC Input Capable, Universal Input
Size / Dimension 2.95Lx1.36W x 1.04 H 75.0mmx34.5mmx26.4mm
Series EML15 (15W)
Published 2014
Operating Temperature -20°C~70°C With Derating
Physical
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount
Supply Chain
Factory Lead Time 17 Weeks
