ECS45US48

XP Power
RoHS
RoHS RoHS compliant
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description XP POWER ECS45US48 AC/DC Open Frame Power Supply, Medical, Adjustable, Fixed, 1 Output, 80 V, 264 V, 45 W, 48 V
PDF
/
Buying Options
Total Price: USD $38.2
Unit Price: USD $38.2024
≥1 USD $38.2024
≥10 USD $36.04
≥100 USD $34
≥1000 USD $30.25988
Inventory: 3858
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 50.8mm
Length 76.2mm
Height 26.7mm

Technical

Max Input Voltage (AC) 264V
Min Input Voltage (AC) 80V
Nominal Output Voltage 48V
Minimum Load Required No
Max Output Power 45W
Current - Output 1 950mA
Max Input Voltage 264V
Min Input Voltage 80V
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Output Power 45W
Output Current 950mA
Voltage - Input 80V~264VAC
Max Output Current 950mA
Output Voltage 48V
Voltage - Isolation 4kV
Efficiency 90%
Approval Agency CB
Number of Outputs 1
Max Power Dissipation 45W
Power Rating 45W
Subcategory Power Supply Modules
Applications ITE (Commercial), Medical
Type Open Frame
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Adjustable Output, DC Input Capable, Universal Input
Size / Dimension 3.00Lx2.00W x 1.05 H 76.2mmx50.8mmx26.7mm
Series ECS (45W)
Published 2010
Operating Temperature -20°C~70°C With Derating

Physical

Mounting Type Chassis Mount
Mount Chassis, Chassis Mount

Supply Chain

Factory Lead Time 24 Weeks
