ECS45US12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
XP POWER ECS45US12 AC/DC Open Frame Power Supply, Medical, Adjustable, Fixed, 1 Output, 80 V, 264 V, 45 W, 12 V
PDF
/
Buying Options
Total Price: USD $38.2
Unit Price: USD $38.2024
≥1 USD $38.2024
≥10 USD $36.04
≥100 USD $34
≥500 USD $32.07547
≥1000 USD $30.25988
≥3000 USD $28.54706
Inventory: 6681
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mount Chassis, Chassis Mount
Mounting Type Chassis Mount
Technical
Operating Temperature -20°C~70°C With Derating
Published 2010
Series ECS (45W)
Size / Dimension 3.00Lx2.00W x 1.05 H 76.2mmx50.8mmx26.7mm
Feature Adjustable Output, DC Input Capable, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Open Frame
Applications ITE (Commercial), Medical
Subcategory Power Supply Modules
Power Rating 45W
Max Power Dissipation 45W
Number of Outputs 1
Approval Agency CB
Efficiency 90%
Voltage - Isolation 4kV
Output Voltage 12V
Max Output Current 3.75A
Voltage - Input 80V~264VAC
Output Current 3.75A
Output Power 45W
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Min Input Voltage 80V
Max Input Voltage 264V
Current - Output 1 3.75A
Max Output Power 45W
Minimum Load Required No
Nominal Output Voltage 12V
Min Input Voltage (AC) 80V
Max Input Voltage (AC) 264V
Dimensions
Height 26.7mm
Length 76.2mm
Width 50.8mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
