ECS45US05
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
XP POWER ECS45US05 AC/DC Open Frame Power Supply, Medical, Adjustable, Fixed, 1 Output, 80 V, 264 V, 30 W, 5 V
PDF
/
Buying Options
Total Price: USD $44.94
Unit Price: USD $44.944
≥1 USD $44.944
≥10 USD $42.4
≥100 USD $40
≥500 USD $37.73585
≥1000 USD $35.59986
Inventory: 8310
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 50.8mm
Length 76.2mm
Height 26.7mm
Technical
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 80V
Nominal Output Voltage 5V
Minimum Load Required No
Max Output Power 30W
Current - Output 1 6A
Max Input Voltage 264V
Min Input Voltage 80V
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Output Power 45W
Output Current 6A
Voltage - Input 80V~264VAC
Max Output Current 6A
Output Voltage 5V
Voltage - Isolation 4kV
Efficiency 90%
Approval Agency CB
Number of Outputs 1
Max Power Dissipation 45W
Power Rating 30W
Subcategory Power Supply Modules
Applications ITE (Commercial), Medical
Type Open Frame
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Adjustable Output, DC Input Capable, Universal Input
Size / Dimension 3.00Lx2.00W x 1.05 H 76.2mmx50.8mmx26.7mm
Series ECS (45W)
Published 2010
Operating Temperature -20°C~70°C With Derating
Physical
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount
Supply Chain
Factory Lead Time 24 Weeks
