ECS100US15
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
XP POWER ECS100US15 AC/DC Open Frame Power Supply, Medical, Adjustable, Fixed, 1 Output, 80 V, 264 V, 80 W, 15 V
PDF
/
Buying Options
Total Price: USD $71.66
Unit Price: USD $71.656
≥1 USD $71.656
≥10 USD $67.6
≥100 USD $63.77358
≥1000 USD $56.75826
Inventory: 7484
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mount Chassis, Chassis Mount
Mounting Type Chassis Mount
Technical
Operating Temperature -20°C~70°C With Derating
Published 2010
Series ECS (100W)
Size / Dimension 4.00Lx2.00W x 1.25 H 101.6mmx50.8mmx31.8mm
Feature Adjustable Output, DC Input Capable, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Open Frame
Applications ITE (Commercial), Medical
Power (Watts) 80W 100W Forced Air
Subcategory Power Supply Modules
Power Rating 100W
Max Power Dissipation 80W
Number of Outputs 1
Approval Agency CB
Efficiency 90%
Voltage - Isolation 4kV
Output Voltage 15V
Max Output Current 6.7A
Voltage - Input 80V~264VAC
Output Current 6.7A
Output Power 80W
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Min Input Voltage 80V
Max Input Voltage 264V
Current - Output 1 6.7A
Max Output Power 80W
Minimum Load Required No
Nominal Output Voltage 15V
Min Input Voltage (AC) 80V
Max Input Voltage (AC) 264V
Dimensions
Height 30.5mm
Width 50.8mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
