ECP40UD02
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
XP POWER ECP40UD02 AC/DC Open Frame Power Supply, Adjustable, Fixed, 2 Output, 85 V, 264 V, 40 W, 5 V
PDF
/
Inventory: 1819
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 50.8mm
Length 88.9mm
Height 22mm
Technical
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 85V
Current - Output 2 1.5A
Minimum Load Required Yes
Max Output Power 40W
Current - Output 1 5A
Max Input Voltage 264V
Min Input Voltage 85V
Voltage - Output 2 15V
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Output Power 40W
Output Current 5A
Voltage - Input 85V~264VAC
Current - Output (Max) 5A 1.5A
Max Output Current 1.5A
Output Voltage 5V
Voltage - Isolation 4kV
Efficiency 90%
Approval Agency CB, CE, TUV, UL
Number of Outputs 2
Max Power Dissipation 40W
Power Rating 40W
Subcategory Power Supply Modules
Applications ITE (Commercial), Medical
Type Open Frame
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Adjustable Output, Universal Input
Size / Dimension 3.50Lx2.00W x 1.01 H 88.9mmx50.8mmx26.0mm
Series ECP (40W)
Published 2009
Operating Temperature -10°C~70°C With Derating
Physical
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount
Supply Chain
Factory Lead Time 18 Weeks
