ECM100US24
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
XP POWER ECM100US24 AC/DC Open Frame Power Supply, Medical, Adjustable, Fixed, 1 Output, 90 V, 264 V, 100 W, 24 V
PDF
/
Buying Options
Total Price: USD $109.55
Unit Price: USD $109.551
≥1 USD $109.551
≥10 USD $103.35
≥100 USD $97.5
≥500 USD $91.98113
≥1000 USD $86.77465
Inventory: 6062
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 63.5mm
Height 26.924mm
Technical
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 90V
Input Current 900μA
Nominal Output Voltage 24V
Minimum Load Required No
Max Output Power 100W
Current - Output 1 4.1A
Max Input Voltage 264V
Min Input Voltage 90V
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Output Power 100W
Output Current 4.1A
Voltage - Input 90V~264VAC 120V~370VDC
Max Output Current 4.1A
Output Voltage 24V
Voltage - Isolation 4kV
Efficiency 80%
Approval Agency CB, CE
Number of Outputs 1
Frequency 63Hz
Max Power Dissipation 100W
Power Rating 100W
Subcategory Power Supply Modules
Applications ITE (Commercial), Medical
Type Open Frame
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Adjustable Output, Universal Input
Size / Dimension 4.50Lx2.50W x 1.20 H 114.3mmx63.5mmx30.5mm
Series ECM (100W)
Published 2004
Operating Temperature 0°C~70°C With Derating
Physical
Package / Case 100
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount
Supply Chain
Factory Lead Time 24 Weeks
