ECM100US05
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
XP POWER ECM100US05 AC/DC Open Frame Power Supply, Medical, Adjustable, Fixed, 1 Output, 90 V, 264 V, 75 W, 5 V
PDF
/
Buying Options
Total Price: USD $109.55
Unit Price: USD $109.551
≥1 USD $109.551
≥10 USD $103.35
≥100 USD $97.5
Inventory: 4162
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 63.5mm
Height 30.5mm
Technical
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 90V
Current - Output 2 20A
Input Current 900μA
Nominal Output Voltage 5V
Minimum Load Required No
Max Output Power 75W
Current - Output 1 20A
Max Input Voltage 264V
Min Input Voltage 90V
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Output Power 100W
Voltage - Input 90V~264VAC 120V~370VDC
Max Output Current 15A
Output Voltage 5V
Voltage - Isolation 4kV
Efficiency 80%
Approval Agency CB, CE
Number of Outputs 1
Frequency 63Hz
Max Power Dissipation 100W
Power Rating 100W
Subcategory Power Supply Modules
Applications ITE (Commercial), Medical
Type Open Frame
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Adjustable Output, Universal Input
Size / Dimension 4.50Lx2.50W x 1.20 H 114.3mmx63.5mmx30.5mm
Series ECM (100W)
Published 2004
Operating Temperature 0°C~70°C With Derating
Physical
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount
Supply Chain
Factory Lead Time 24 Weeks
