ECM100US03
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
XP POWER ECM100US03 AC/DC Open Frame Power Supply, Medical, Adjustable, Fixed, 1 Output, 90 V, 264 V, 49.5 W, 3.3 V
PDF
/
Buying Options
Total Price: USD $115.54
Unit Price: USD $115.54
≥1 USD $115.54
≥10 USD $109
≥100 USD $102.83019
Inventory: 67
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mount Chassis, Chassis Mount
Mounting Type Chassis Mount
Technical
Operating Temperature 0°C~70°C With Derating
Published 2004
Series ECM (100W)
Size / Dimension 4.50Lx2.50W x 1.20 H 114.3mmx63.5mmx30.5mm
Feature Adjustable Output, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Open Frame
Applications ITE (Commercial), Medical
Subcategory Power Supply Modules
Power Rating 100W
Max Power Dissipation 100W
Frequency 63Hz
Number of Outputs 1
Approval Agency CB, CE
Efficiency 80%
Voltage - Isolation 4kV
Output Voltage 3.3V
Max Output Current 15A
Voltage - Input 90V~264VAC 120V~370VDC
Output Power 100W
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Min Input Voltage 90V
Max Input Voltage 264V
Current - Output 1 20A
Max Output Power 49.5W
Minimum Load Required No
Nominal Output Voltage 3.3V
Input Current 900μA
Current - Output 2 20A
Min Input Voltage (AC) 90V
Max Input Voltage (AC) 264V
Dimensions
Height 30.48mm
Width 63.5mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
