ECL30UT02-P

XP Power
RoHS
RoHS RoHS compliant
Package 7-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description XP POWER ECL30UT02-P AC/DC PCB Mount Power Supply, Adjustable, Fixed, 3 Output, 85 V, 264 V, 30 W, 5 V
PDF
/
Inventory: 3684
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Height 22.3mm

Technical

Current - Output 3 630mA
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 85V
Load Regulation ±1%
Line Regulation ±0.5%
Current - Output 2 630mA
Max Output Power 30W
Voltage - Output 3 -12V
Current - Output 1 3A
Max Input Voltage 264V
Min Input Voltage 85V
Voltage - Output 2 12V
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Output Power 30W
Output Current 3A
Voltage - Input 85V~264VAC
Current - Output (Max) 3A 630mA 630mA
Max Output Current 3A
Output Voltage 5V
Efficiency 83%
Approval Agency CSA, cUL, EN, IEC, UL
Number of Outputs 3
Depth 75.2mm
Max Power Dissipation 30W
Power Rating 30W
Subcategory Power Supply Modules
Applications ITE (Commercial)
Type Open Frame
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OVP, SCP
Size / Dimension 2.96Lx1.36W x 1.05 H 75.2mmx34.6mmx26.7mm
Series ECL (30W)
Published 2000
Operating Temperature -20°C~70°C With Derating

Physical

Weight 0.132lb 59.87g
Package / Case 7-DIP Module
Mounting Type Through Hole
Mount PCB, Through Hole

Supply Chain

Factory Lead Time 17 Weeks
