ECL30UD01-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
XP POWER ECL30UD01-S AC/DC Enclosed Power Supply, Fixed, 2 Outputs, 85 V, 264 V, 30 W, 12 V
PDF
/
Buying Options
Total Price: USD $76.4
Unit Price: USD $76.4048
≥1 USD $76.4048
≥10 USD $72.08
≥100 USD $68
Inventory: 4812
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Chassis Mount, Panel
Mounting Type Chassis Mount
Technical
Operating Temperature -20°C~70°C With Derating
Published 2008
Series ECL (30W)
Size / Dimension 3.78Lx1.57W x 1.12 H 96.0mmx40.0mmx28.5mm
Feature Adjustable Output, DC Input Capable, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Enclosed
Applications ITE (Commercial)
Power Rating 30W
Max Power Dissipation 30W
Number of Outputs 2
Efficiency 84%
Voltage - Isolation 3kV
Output Voltage 12V
Max Output Current 1.3A
Current - Output (Max) 1.3A 1.3A
Voltage - Input 85V~264VAC
Output Current 1.3A
Output Power 31.2W
Voltage - Output 2 -12V
Min Input Voltage 85V
Max Input Voltage 264V
Current - Output 1 1.3A
Max Output Power 30W
Minimum Load Required Yes
Current - Output 2 1.3A
Min Input Voltage (AC) 85V
Max Input Voltage (AC) 264V
Dimensions
Height 28.5mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
