ECL25US24-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
PSU, SCREW TERMINAL, 25W, 24V
PDF
/
Buying Options
Total Price: USD $62.36
Unit Price: USD $62.3598
≥1 USD $62.3598
≥10 USD $58.83
≥100 USD $55.5
Inventory: 347
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 28.5mm
Technical
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 85V
Nominal Output Voltage 24V
Minimum Load Required No
Max Output Power 25W
Current - Output 1 1.04A
Max Input Voltage 264V
Min Input Voltage 85V
Output Power 25W
Output Current 1.04A
Voltage - Input 85V~264VAC
Trim/Adjustable Output NO
Input Voltage-Nom 115V
Max Output Current 1.04A
Output Voltage 24V
Voltage - Isolation 3kV
Efficiency 82%
Number of Outputs 1
JESD-30 Code R-XXFM-X6
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 25W
Power Rating 25W
Applications ITE (Commercial)
Type Enclosed
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Adjustable Output, DC Input Capable, Universal Input
Size / Dimension 3.78Lx1.57W x 1.12 H 96.0mmx40.0mmx28.5mm
Series ECL (25W)
Published 2011
Operating Temperature -20°C~70°C With Derating
Physical
Mounting Type Chassis Mount
Mount Chassis Mount, Panel
Supply Chain
Factory Lead Time 17 Weeks
