ECL25US05-T

XP Power
RoHS
RoHS RoHS compliant
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description XP POWER ECL25US05-TAC/DC Open Frame Power Supply, Ultra Compact, Adjustable, Fixed, 85 V, 264 V, 25 W, 5 V, 5 A
PDF
/
Buying Options
Total Price: USD $41.2
Unit Price: USD $41.2
≥1 USD $41.2
≥10 USD $38.86792
≥100 USD $36.66785
Inventory: 92
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 17 Weeks

Physical

Mount Chassis Mount, Panel
Mounting Type Chassis Mount

Technical

Operating Temperature -20°C~70°C With Derating
Published 2009
Series ECL (25W)
Size / Dimension 3.46Lx1.36W x 0.88 H 87.9mmx34.6mmx22.4mm
Feature Adjustable Output, DC Input Capable, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Open Frame
Applications ITE (Commercial)
Subcategory Power Supply Modules
Power Rating 25W
Max Power Dissipation 25W
Number of Outputs 1
Approval Agency CE
Efficiency 78%
Voltage - Isolation 4kV
Output Voltage 5V
Max Output Current 5A
Voltage - Input 85V~264VAC
Output Current 5A
Output Power 25W
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Min Input Voltage 85V
Max Input Voltage 264V
Current - Output 1 5A
Max Output Power 25W
Minimum Load Required No
Nominal Output Voltage 5V
Input Current 400μA
Min Input Voltage (AC) 85V
Max Input Voltage (AC) 264V

Dimensions

Height 22.352mm
Length 87.9mm
Width 25.4mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
