ECL15UT03-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC PSU, 3 O/P, 15W, SCREW TERM
PDF
/
Buying Options
Total Price: USD $61.35
Unit Price: USD $61.34856
≥1 USD $61.34856
≥10 USD $57.876
≥100 USD $54.6
Inventory: 90
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 26.4mm
Technical
Current - Output 3 150mA
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 85V
Current - Output 2 150mA
Minimum Load Required Yes
Max Output Power 15W
Voltage - Output 3 -15V
Current - Output 1 2A
Max Input Voltage 264V
Min Input Voltage 85V
Voltage - Output 2 15V
Output Power 14.5W
Output Current 2A
Voltage - Input 85V~264VAC
Current - Output (Max) 2A 150mA 150mA
Max Output Current 2A
Output Voltage 5V
Voltage - Isolation 3kV
Efficiency 81%
Number of Outputs 3
Max Power Dissipation 15W
Power Rating 15W
Applications ITE (Commercial)
Type Enclosed
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Adjustable Output, DC Input Capable, Universal Input
Size / Dimension 3.30Lx1.36W x 1.04 H 84.0mmx34.5mmx26.4mm
Series ECL (15W)
Published 2008
Operating Temperature -20°C~70°C With Derating
Physical
Mounting Type Chassis Mount
Mount Chassis Mount, Panel
Supply Chain
Factory Lead Time 17 Weeks
