ECL15US15-T
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
XP POWER ECL15US15-TAC/DC Open Frame Power Supply, Ultra Compact, Adjustable, Fixed, 85 V, 264 V, 15 W, 15 V, 1 A
PDF
/
Buying Options
Total Price: USD $31.24
Unit Price: USD $31.23608
≥1 USD $31.23608
≥10 USD $29.468
≥100 USD $27.8
≥1000 USD $24.7419
≥3000 USD $23.34142
Inventory: 8910
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Length 78.7mm
Height 23.13mm
Technical
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 85V
Nominal Output Voltage 15V
Minimum Load Required No
Max Output Power 15W
Current - Output 1 1A
Max Input Voltage 264V
Min Input Voltage 85V
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Output Power 15W
Output Current 1A
Voltage - Input 85V~264VAC
Max Output Current 1A
Output Voltage 15V
Voltage - Isolation 3kV
Efficiency 80%
Approval Agency CSA, EN, IEC, UL
Number of Outputs 1
Max Power Dissipation 15W
Power Rating 15W
Subcategory Power Supply Modules
Applications ITE (Commercial)
Type Open Frame
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Adjustable Output, DC Input Capable, Universal Input
Size / Dimension 3.10Lx1.25W x 0.78 H 78.7mmx31.7mmx20.0mm
Series ECL (15W)
Published 2002
Operating Temperature -20°C~70°C With Derating
Physical
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount
Supply Chain
Factory Lead Time 17 Weeks
