ECL05US48-E
RoHS
RoHS compliant
RoHS compliantPackage 4-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description
XP POWER ECL05US48-EAC/DC PCB Mount Power Supply, Ultra Compact, Adjustable, Fixed, 85 V, 264 V, 5 W, 48 V, 100 mA
PDF
/
Buying Options
Total Price: USD $31
Unit Price: USD $31
≥1 USD $31
≥10 USD $29.24528
≥100 USD $27.58989
≥500 USD $26.0282
≥1000 USD $24.5549
Inventory: 2088
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 27.2mm
Height 23mm
Technical
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 85V
Load Regulation ±1%
Line Regulation ±0.5%
Nominal Output Voltage 48V
Max Output Power 5W
Current - Output 1 100mA
Max Input Voltage 264V
Min Input Voltage 85V
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Output Power 5W
Output Current 100mA
Voltage - Input 85V~264VAC
Max Output Current 100mA
Output Voltage 48V
Efficiency 82%
Approval Agency CSA, cUL, EN, IEC, UL
Number of Outputs 1
Depth 52.4mm
Max Power Dissipation 5W
Power Rating 5W
Subcategory Power Supply Modules
Applications ITE (Commercial)
Type Enclosed
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OVP, SCP
Size / Dimension 2.06Lx1.07W x 0.91 H 52.3mmx27.2mmx23.0mm
Series ECL (5W)
Published 2011
Operating Temperature -20°C~70°C With Derating
Physical
Weight 0.132lb 59.87g
Package / Case 4-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 17 Weeks
