ECE60US12-SD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
XP POWER ECE60US12-SD AC/DC DIN Rail Power Supply, Ultra Compact, Fixed, 1 Output, 85 VAC, 264 VAC, 60 W, 12 VDC
PDF
/
Buying Options
Total Price: USD $79.54
Unit Price: USD $79.542742
≥1 USD $79.542742
≥10 USD $75.040326
≥100 USD $70.792757
≥500 USD $66.785619
≥1000 USD $63.005301
Inventory: 1501
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount DIN Rail
Mounting Type DIN Rail
Technical
Operating Temperature -40°C~70°C With Derating
Published 2014
Series ECE60 (60W)
Size / Dimension 4.45Lx1.57W x 1.12 H 113.0mmx40.0mmx28.5mm
Feature DC Input Capable, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Enclosed
Applications ITE (Commercial)
Subcategory Power Supply Modules
Max Power Dissipation 60W
Number of Outputs 1
Approval Agency CB, TUV, UL
Efficiency 87%
Voltage - Isolation 3kV
Output Voltage 12V
Max Output Current 5A
Max Voltage Rating (AC) 264V
Voltage - Input 85V~264VAC
Output Power 60W
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Min Input Voltage 85V
Max Input Voltage 264V
Current - Output 1 5A
Max Output Power 60W
Minimum Load Required No
Nominal Output Voltage 12V
Min Input Voltage (AC) 85V
Max Input Voltage (AC) 264V
Dimensions
Height 28.448mm
Width 40mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
