DPC70US12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 12V 70W
PDF
/
Buying Options
Total Price: USD $57.71
Unit Price: USD $57.7081
≥1 USD $57.7081
≥10 USD $54.4416
≥100 USD $51.36
≥500 USD $48.45283
≥1000 USD $45.71022
Inventory: 4493
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Physical
Mounting Type DIN Rail
Technical
Operating Temperature -25°C~70°C With Derating
Published 2017
Series DPC70 (70W)
Size / Dimension 3.94Lx1.59W x 3.60 H 100.0mmx40.5mmx90.0mm
Feature Adjustable Output, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Enclosed
Applications ITE (Commercial)
Power (Watts) 70W
Number of Outputs 1
Approval Agency CE
Efficiency 89%
Voltage - Isolation 3kV
Voltage - Output 1 12V
Current - Output (Max) 5.5A
Voltage - Input 85V~264VAC
Output Power 66W
Minimum Load Required No
Compliance
RoHS Status ROHS3 Compliant
