CCB250PS48
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 48V 250W
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Physical
Mounting Type Chassis Mount
Technical
Operating Temperature -20°C~70°C With Derating
Published 2015
Series CCB250 (250W)
Size / Dimension 6.00Lx4.00W x 1.50 H 152.4mmx101.6mmx38.1mm
Feature Adjustable Output, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Open Frame
Applications ITE (Commercial), Medical
Number of Outputs 1
Approval Agency CB, TUV, UL
Efficiency 95%
Voltage - Isolation 4kV
Voltage - Output 1 48V
Current - Output (Max) 5.2A
Voltage - Input 80V~275VAC
Output Power 250W
Minimum Load Required No
Compliance
RoHS Status ROHS3 Compliant
