ASB110PS12
RoHS
RoHS compliant
RoHS compliantPackage 5-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description
XP POWER ASB110PS12AC/DC PCB Mount Power Supply, Base Plate Cooled, Fixed, 85 V, 264 V, 110 W, 12 V, 9.17 A
PDF
/
Buying Options
Total Price: USD $220
Unit Price: USD $220
≥1 USD $220
≥10 USD $207.54717
≥100 USD $195.79922
≥500 USD $184.71624
≥1000 USD $174.26061
Inventory: 7239
Minimum: 1
-
+
Technical Details
Dimensions
Height 17mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Technical
Warm-up Time 0.02 s
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 85V
Line Regulation ±0.5%
Nominal Output Voltage 12V
Max Output Power 110W
Current - Output 1 9.17A
Max Input Voltage 264V
Min Input Voltage 85V
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL
Output Power 110W
Voltage - Input 85V~264VAC
Trim/Adjustable Output NO
Input Voltage-Nom 115V
Max Output Current 7.33A
Output Voltage 12V
Efficiency 90%
Approval Agency CB, CE, cURus, TUVgs
Number of Outputs 1
JESD-30 Code R-XDMA-P5
Depth 116.8mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 110W
Subcategory Power Supply Modules
Applications ITE (Commercial)
Type Enclosed
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OTP, OVP
Size / Dimension 4.60Lx2.40W x 0.67 H 116.8mmx61.0mmx17.0mm
Series ASB110 (110W)
Published 2014
Operating Temperature -40°C~85°C With Derating
Physical
Weight 0.51lb 231.33g
Package / Case 5-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
