TXL 100-15S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 15V 105W
PDF
/
Inventory: 4661
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Minimum Load Required Yes
Voltage - Input 85V~264VAC 120V~375VDC
Current - Output (Max) 7A
Trim/Adjustable Output YES
Input Voltage-Nom 100V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Isolation 3kV
Efficiency 84%
Approval Agency CE, cURus
Number of Outputs 1
JESD-30 Code R-MXMA-X7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Power (Watts) 105W
Applications ITE (Commercial)
Type Enclosed
Number of Terminations 7
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Adjustable Output, Universal Input
Size / Dimension 7.80Lx3.74W x 1.50 H 198.1mmx95.0mmx38.1mm
Series TXL 100 (100W)
Published 2015
Operating Temperature -20°C~70°C With Derating
Physical
Surface Mount NO
Mounting Type Chassis Mount
Supply Chain
Factory Lead Time 13 Weeks
