TPP 30-109-J
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 9V 30W
PDF
/
Buying Options
Total Price: USD $83.2
Unit Price: USD $83.19723
≥1 USD $83.19723
≥10 USD $78.48795
≥100 USD $74.04524
≥500 USD $69.854
≥1000 USD $65.9
≥3000 USD $62.16981
Inventory: 6038
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Minimum Load Required No
Voltage - Input 85V~264VAC 120V~370VDC
Current - Output (Max) 3.34A
Voltage - Output 1 9V
Voltage - Isolation 4kV
Efficiency 88%
Approval Agency CB, CE, cURus
Number of Outputs 1
Power (Watts) 30W
Applications Household Appliances, ITE (Commercial), Medical
Type Enclosed
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Adjustable Output, Universal Input
Size / Dimension 3.95Lx1.50W x 1.00 H 100.3mmx38.1mmx25.4mm
Series TPP 30-J (30W)
Operating Temperature -40°C~85°C With Derating
Physical
Mounting Type Chassis Mount
Supply Chain
Factory Lead Time 13 Weeks
