TMP 30215
RoHS
RoHS compliant
RoHS compliantPackage 7-DIP Module, 5 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER +/-15V 30W
PDF
/
Buying Options
Total Price: USD $53.82
Unit Price: USD $53.8208
≥1 USD $53.8208
≥10 USD $41.98656
Inventory: 187
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Load Regulation ±1%
Line Regulation 1%, 3%
Total Power Output-Max 30W
Voltage - Output 2 -15V
Voltage - Input 85V~264VAC 120V~370VDC
Current - Output (Max) 1A 1A
Trim/Adjustable Output NO
Input Voltage-Nom 100V
Voltage - Output 1 15V
Output Voltage 15V
Efficiency 80%
Approval Agency CB, CE, cULus, cURus
Number of Outputs 2
JESD-30 Code R-PXMA-X7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Additional Feature ALSO HAS OUTPUT VOLTAGE -15 V
Power (Watts) 30W
Applications ITE (Commercial)
Type Enclosed
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Universal Input
Size / Dimension 3.50Lx2.50W x 0.85 H 88.9mmx63.5mmx21.7mm
Series TMP (30W)
Published 2012
Operating Temperature -25°C~70°C With Derating
Physical
Surface Mount NO
Package / Case 7-DIP Module, 5 Leads
Mounting Type Through Hole
Supply Chain
Factory Lead Time 11 Weeks
