TMP 15515C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 5V +/-15V 15W
PDF
/
Buying Options
Total Price: USD $56.18
Unit Price: USD $56.18022
≥1 USD $56.18022
≥10 USD $53.00021
≥100 USD $50.0002
≥500 USD $47.17
≥1000 USD $44.5
≥3000 USD $41.98113
Inventory: 8500
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Minimum Load Required Yes
Voltage - Output 3 -15V
Total Power Output-Max 15W
Voltage - Output 2 15V
Voltage - Input 85V~264VAC 120V~370VDC
Current - Output (Max) 2A 150mA 150mA
Trim/Adjustable Output NO
Input Voltage-Nom 100V
Voltage - Output 1 5V
Output Voltage 5V
Voltage - Isolation 3kV
Efficiency 74%
Approval Agency CB, CE, cULus, cURus
Number of Outputs 3
JESD-30 Code R-PXFM-X7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Power (Watts) 15W
Applications Industrial, ITE (Commercial)
Type Enclosed
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Adjustable Output, Universal Input
Size / Dimension 3.78Lx2.13W x 0.92 H 96.0mmx54.1mmx23.4mm
Series TMP (15W)
Published 2010
Operating Temperature -25°C~70°C With Derating
Physical
Surface Mount NO
Mounting Type Chassis Mount
Supply Chain
Factory Lead Time 11 Weeks
