TMP 15112
RoHS
RoHS compliant
RoHS compliantPackage 7-DIP Module, 4 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER 12V 15W
PDF
/
Buying Options
Total Price: USD $36.49
Unit Price: USD $36.4936
≥1 USD $36.4936
≥10 USD $34.34288
≥100 USD $33.269984
≥500 USD $32.196736
≥1000 USD $31.123576
≥3000 USD $30.05031
Inventory: 53
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Through Hole
Package / Case 7-DIP Module, 4 Leads
Surface Mount NO
Technical
Operating Temperature -25°C~70°C With Derating
Published 2010
Series TMP (15W)
Size / Dimension 2.91Lx2.13W x 0.77 H 74.0mmx54.0mmx19.5mm
Feature Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 7
ECCN Code EAR99
Type Enclosed
Applications ITE (Commercial)
Power (Watts) 15W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PXMA-X7
Number of Outputs 1
Approval Agency CB, CE, cULus, cURus
Efficiency 79%
Output Voltage 12V
Voltage - Output 1 12V
Input Voltage-Nom 100V
Trim/Adjustable Output NO
Current - Output (Max) 1.25A
Voltage - Input 85V~264VAC 120V~370VDC
Line Regulation 1%
Load Regulation ±1%
Compliance
RoHS Status ROHS3 Compliant
