TMM 24124
RoHS
RoHS compliant
RoHS compliantPackage 7-DIP Module, 5 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER 24V 24W
PDF
/
Buying Options
Total Price: USD $59.6
Unit Price: USD $59.6024
≥1 USD $59.6024
≥10 USD $46.464
Inventory: 37
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Through Hole
Package / Case 7-DIP Module, 5 Leads
Surface Mount NO
Technical
Operating Temperature -40°C~80°C With Derating
Published 2014
Series TMM 24 (24W)
Size / Dimension 2.91Lx2.13W x 0.77 H 74.0mmx54.0mmx19.5mm
Feature Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 5
ECCN Code EAR99
Type Enclosed
Applications Industrial, ITE (Commercial), Medical
Power (Watts) 24W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-P5
Number of Outputs 1
Approval Agency CB, CE, cULus, cURus
Efficiency 85%
Output Voltage 24V
Voltage - Output 1 24V
Input Voltage-Nom 100V
Trim/Adjustable Output NO
Current - Output (Max) 1A
Voltage - Input 85V~264VAC 120V~370VDC
Total Power Output-Max 24W
Line Regulation 0.5%
Dimensions
Height Seated (Max) 20mm
Length 74mm
Width 54mm
Compliance
RoHS Status ROHS3 Compliant
