TMLM 20103
RoHS
RoHS compliant
RoHS compliantPackage 4-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER 3.3V 12W
PDF
/
Buying Options
Total Price: USD $44
Unit Price: USD $43.99568
≥1 USD $43.99568
≥10 USD $41.50536
≥100 USD $39.156
Inventory: 94
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 27.2mm
Length 52.4mm
Height Seated (Max) 24mm
Technical
Voltage - Input 90V~264VAC 120V~370VDC
Current - Output (Max) 3.6A
Trim/Adjustable Output NO
Input Voltage-Nom 100V
Voltage - Output 1 3.3V
Output Voltage 3.3V
Efficiency 74%
Approval Agency CE, cURus
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PDMA-P4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Subcategory Power Supply Modules
Power (Watts) 12W
Applications ITE (Commercial)
Type Enclosed
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature Universal Input
Size / Dimension 2.06Lx1.07W x 0.93 H 52.4mmx27.2mmx23.5mm
Series TMLM (20W)
Published 2013
Operating Temperature -25°C~60°C With Derating
Physical
Surface Mount NO
Package / Case 4-DIP Module
Mounting Type Through Hole
Supply Chain
Factory Lead Time 10 Weeks
