TML 40515
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP Module, 7 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER 5V +/-15V 40W
PDF
/
Buying Options
Total Price: USD $92.35
Unit Price: USD $92.3472
≥1 USD $92.3472
≥10 USD $86.66592
≥100 USD $83.824224
≥500 USD $80.982528
≥1000 USD $78.141096
≥3000 USD $70.334
Inventory: 37
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Package / Case 8-DIP Module, 7 Leads
Surface Mount NO
Technical
Operating Temperature -40°C~60°C With Derating
Published 2007
Series TML (40W)
Size / Dimension 3.52Lx2.52W x 0.98 H 89.5mmx64.1mmx25.0mm
Feature Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 7
ECCN Code EAR99
Type Enclosed
Applications ITE (Commercial)
Power (Watts) 40W
Additional Feature ALSO HAS OUTPUT VOLTAGE -15 V AND 15 V
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-P7
Number of Outputs 3
Approval Agency CB, CE, cURus
Efficiency 84%
Output Voltage 5V
Voltage - Output 1 5V
Input Voltage-Nom 115V
Trim/Adjustable Output NO
Current - Output (Max) 5A 500mA 500mA
Voltage - Input 90V~264VAC 100V~375VDC
Voltage - Output 2 15V
Total Power Output-Max 40W
Voltage - Output 3 -15V
Dimensions
Height Seated (Max) 25mm
Length 89mm
Compliance
RoHS Status ROHS3 Compliant
