TML 20124
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP Module, 5 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER 24V 20W
PDF
/
Buying Options
Total Price: USD $49.88
Unit Price: USD $49.8784
≥1 USD $49.8784
≥10 USD $46.85384
≥100 USD $45.342176
≥500 USD $43.830688
≥1000 USD $42.319288
≥3000 USD $37.410982
Inventory: 61
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Package / Case 8-DIP Module, 5 Leads
Surface Mount NO
Technical
Operating Temperature -25°C~70°C With Derating
Published 2007
Series TML (20W)
Size / Dimension 2.74Lx1.87W x 0.85 H 69.5mmx47.5mmx21.7mm
Feature Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 8
ECCN Code EAR99
Type Enclosed
Applications ITE (Commercial)
Power (Watts) 20W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-P8
Number of Outputs 1
Approval Agency CB, CE, cURus
Efficiency 84%
Output Voltage 24V
Voltage - Output 1 24V
Input Voltage-Nom 115V
Trim/Adjustable Output NO
Current - Output (Max) 840mA
Voltage - Input 90V~264VAC 100V~375VDC
Total Power Output-Max 20W
Dimensions
Height Seated (Max) 22mm
Length 70mm
Width 48mm
Compliance
RoHS Status ROHS3 Compliant
