TBLC 50-124
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 24V 50W
PDF
/
Inventory: 6270
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Total Power Output-Max 50W
Voltage - Input 85V~264VAC
Current - Output (Max) 2.1A
Trim/Adjustable Output YES
Input Voltage-Nom 100V
Voltage - Output 1 24V
Output Voltage 24V
Voltage - Isolation 3kV
Efficiency 89%
Approval Agency CB, CE, cULus, cURus, SIQ
Number of Outputs 1
JESD-30 Code R-PXMA-X3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Power (Watts) 50W
Applications Household Appliances, Industrial, ITE (Commercial)
Type Enclosed
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Adjustable Output, IP20, Universal Input
Size / Dimension 2.15Lx2.13W x 3.52 H 54.6mmx54.1mmx89.4mm
Series TBLC (50W)
Published 2017
Operating Temperature -25°C~70°C With Derating
Physical
Surface Mount NO
Mounting Type DIN Rail
Supply Chain
Factory Lead Time 6 Weeks
