ZWS50-36
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 36V 50W
PDF
/
Inventory: 6468
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 1 month ago)
Physical
Mount Chassis Mount, Panel
Mounting Type Chassis Mount
Number of Pins 7
Weight 249.999986g
Technical
Operating Temperature -10°C~60°C With Derating
Published 1999
Series ZWS (50W)
Size / Dimension 7.68Lx2.17W x 1.02 H 195.0mmx55.1mmx25.9mm
Feature Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Open Frame
Applications ITE (Commercial)
Subcategory Power Supply Modules
Power Rating 50W
Max Power Dissipation 50W
Depth 55.1mm
Number of Outputs 1
Approval Agency CE, cURus, TUV
Efficiency 80%
Voltage - Isolation 3kV
Output Voltage 36V
Max Output Current 1.4A
Voltage - Input 85V~265VAC
Output Current 1.4A
Output Power 50W
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Current - Output 1 1.4A
Dimensions
Height 25.908mm
Compliance
RoHS Status RoHS Compliant
