RFE1000-24-Y
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 24V 960W
PDF
/
Buying Options
Total Price: USD $524.18
Unit Price: USD $524.1808
≥1 USD $524.1808
≥10 USD $471.11856
Inventory: 128
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Chassis Mount, Panel
Mounting Type Chassis Mount
Number of Pins 15
Weight 600.102706g
Technical
Operating Temperature 0°C~70°C With Derating
Published 2012
Series RFE (1000)
Size / Dimension 12.00Lx5.00W x 1.60 H 305.0mmx127.0mmx41.0mm
Feature Adjustable Output, Load Sharing, Remote On/Off, Remote Sense, Standby Output, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Enclosed
Applications ITE (Commercial)
Additional Feature REMOTE SHUTDOWN
Subcategory Power Supply Modules
Power Rating 1kW
Max Power Dissipation 960W
Depth 127mm
Number of Outputs 1
Approval Agency CE
Efficiency 86%
Voltage - Isolation 3kV
Output Voltage 24V
Max Output Current 40A
Voltage - Input 85V~265VAC
Output Current 40A
Output Power 960W
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL
Min Input Voltage 85V
Max Input Voltage 265V
Current - Output 1 40A
Nominal Input Voltage 265V
Max Output Power 960W
Nominal Output Voltage 24V
Dimensions
Height 41mm
Length 305mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
