RoHS
/
Package 11-DIP Module, Full Brick
Category Power Supplies - Board Mount / AC DC Converters
Description AC/DC CONVERTER 12V 33A 500W
PDF
/
Inventory: 2073
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case 11-DIP Module, Full Brick
Number of Pins 8
Weight 0.662lb 300.28g

Technical

Operating Temperature -40°C~100°C With Derating
Published 2007
Series PFE500S (500W)
Size / Dimension 4.80Lx2.76W x 0.50 H 122.0mmx70.0mmx12.7mm
Feature OCP, OTP, OVP
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Enclosed
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications ITE (Commercial)
Power (Watts) 500W
Power Rating 396W
Max Power Dissipation 500W
Depth 61mm
Number of Outputs 1
Approval Agency CE, cULus
Efficiency 83%
Output Voltage 12V
Max Output Current 33A
Voltage - Output 1 12V
Max Current Rating 6.2A
Current - Output (Max) 33A
Voltage - Input 85V~265VAC
Output Current 33A
Output Power 396W
Current - Output 1 33A
Max Output Power 396W
Line Regulation 48mV
Load Regulation 48mV

Dimensions

Height 12.7mm
Length 116.8mm
Width 70.104mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
