PFE500F-12
RoHS
RoHS compliant
RoHS compliantPackage 17-DIP Module, Full Brick
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER 12V 42A 500W
PDF
/
Buying Options
Total Price: USD $383.4
Unit Price: USD $383.3984
≥1 USD $383.3984
≥10 USD $319.49984
≥100 USD $287.381248
Inventory: 32
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 17-DIP Module, Full Brick
Number of Pins 8
Weight 0.662lb 300.28g
Technical
Operating Temperature -40°C~100°C With Derating
Published 2007
Series PFE500F (500W)
Size / Dimension 4.80Lx2.76W x 0.50 H 122.0mmx70.0mmx12.7mm
Feature Remote On/Off, OCP, OTP, OVP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Enclosed
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications ITE (Commercial)
Power (Watts) 500W
Power Rating 504W
Max Power Dissipation 500W
Depth 61mm
Number of Outputs 1
Approval Agency CE, cULus
Efficiency 83%
Output Voltage 12V
Max Output Current 42A
Voltage - Output 1 12V
Max Current Rating 6.8A
Current - Output (Max) 42A
Voltage - Input 85V~265VAC
Output Current 42A
Output Power 504W
Current - Output 1 42A
Max Output Power 504W
Line Regulation 48mV
Load Regulation 48mV
Dimensions
Height 12.7mm
Length 122mm
Width 70mm
Compliance
RoHS Status RoHS Compliant
