KWS25A-15
RoHS
RoHS compliant
RoHS compliantPackage 4-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description
TDK LAMBDA KWS25A-15 POWER SUPPLY, AC-DC, 15V, 1.7A
PDF
/
Buying Options
Total Price: USD $33.42
Unit Price: USD $33.4224
≥1 USD $33.4224
≥10 USD $31.68
Inventory: 77
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Height 29mm
Technical
Max Input Voltage (AC) 265V
Min Input Voltage (AC) 85V
Load Regulation 120mV
Line Regulation 60mV
Max Output Power 25.5W
Current - Output 1 1.7A
Max Input Voltage 265V
Min Input Voltage 85V
Output Power 25.5W
Voltage - Input 85V~265VAC 120V~370VDC
Trim/Adjustable Output NO
Input Voltage-Nom 100V
Voltage - Output 1 15V
Max Output Current 1.7A
Output Voltage 15V
Efficiency 87%
Approval Agency CE
Number of Outputs 1
JESD-30 Code R-PDMA-P4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 63.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 25W
Applications ITE (Commercial)
Type Enclosed
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Universal Input
Size / Dimension 2.50Lx1.00W x 1.14 H 63.5mmx25.4mmx29.0mm
Series KWS-A (25W)
Published 2015
Operating Temperature -10°C~85°C With Derating
Physical
Package / Case 4-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 13 Weeks
