KWS15A-12 image
Favorite
KWS15A-12 image
Favorite
RoHS
RoHS RoHS compliant
Package 4-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description TDK LAMBDA KWS15A-12 POWER SUPPLY, AC-DC, 12V, 1.3A
PDF
/
Buying Options
Total Price: USD $29.1
Unit Price: USD $29.1016
≥1 USD $29.1016
≥10 USD $27.588
Inventory: 702
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Height 23.5mm

Technical

Max Input Voltage (AC) 265V
Min Input Voltage (AC) 85V
Load Regulation 48mV
Line Regulation 96mV
Max Output Power 15.6W
Current - Output 1 1.3A
Max Input Voltage 265V
Min Input Voltage 85V
Output Power 15.6W
Voltage - Input 85V~265VAC 120V~370VDC
Trim/Adjustable Output NO
Input Voltage-Nom 100V
Voltage - Output 1 12V
Max Output Current 1.3A
Output Voltage 12V
Efficiency 83%
Approval Agency CE
Number of Outputs 1
JESD-30 Code R-PDMA-P4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 70mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 15W
Applications ITE (Commercial)
Type Enclosed
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Universal Input
Size / Dimension 2.00Lx1.00W x 0.94 H 50.8mmx25.4mmx24.0mm
Series KWS-A (15W)
Published 2015
Operating Temperature -10°C~85°C With Derating

Physical

Package / Case 4-DIP Module
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 13 Weeks
