KPS105
RoHS
RoHS compliant
RoHS compliantPackage 4-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description
PWR SUP BRD MNT 5V 10.0W 2.00A
PDF
/
Inventory: 2160
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 65mm
Height 23.114mm
Technical
Load Regulation ±1%
Line Regulation ±0.5%
Nominal Output Voltage 5V
Max Output Power 10W
Current - Output 1 2A
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Output Power 10W
Output Current 2A
Voltage - Input 85V~264VAC
Max Current Rating 270mA
Trim/Adjustable Output NO
Input Voltage-Nom 115V
Max Output Current 2A
Output Voltage 5V
Efficiency 70%
Approval Agency CE, CSA, EN, UL
Number of Outputs 1
JESD-30 Code R-XXMA-X5
Depth 45mm
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 10W
Power Rating 10W
Subcategory Power Supply Modules
Applications ITE (Commercial)
Type Open Frame
Number of Terminations 5
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Not For New Designs
Feature OVP, SCP
Size / Dimension 2.56Lx1.77W x 0.91 H 65.0mmx45.0mmx23.1mm
Series KPS (10W)
Published 2005
Operating Temperature 0°C~70°C With Derating
Physical
Weight 0.133lb 60.33g
Number of Pins 4
Package / Case 4-DIP Module
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 12 Weeks
