KAS4-5
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER 5V 4W
PDF
/
Buying Options
Total Price: USD $20.55
Unit Price: USD $20.548
≥1 USD $20.548
≥10 USD $18.7616
≥100 USD $17.3096
≥500 USD $16.764176
Inventory: 128
Minimum: 1
-
+
Technical Details
Technical
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Type Enclosed
Applications ITE (Commercial)
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDMA-P6
Number of Outputs 1
Approval Agency CE, cURus
Efficiency 72%
Output Voltage 5V
Voltage - Output 1 5V
Input Voltage-Nom 115V
Trim/Adjustable Output NO
Current - Output (Max) 800mA
Voltage - Input 90V~305VAC
Output Power 4W
Total Power Output-Max 4W
Line Regulation 25mV
Load Regulation 75mV
Size / Dimension 1.46Lx1.08W x 0.69 H 37.1mmx27.4mmx17.5mm
Series KAS (4W)
Published 2017
Operating Temperature -40°C~70°C With Derating
Dimensions
Height 17.5mm
Length 37mm
Width 27.5mm
Compliance
RoHS Status RoHS Compliant
Physical
Surface Mount NO
Package / Case 6-DIP Module
Mounting Type Through Hole
Supply Chain
Factory Lead Time 14 Weeks
