JWS30015
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 15V 300W
PDF
/
Inventory: 6114
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Height 91.948mm
Technical
Max Input Voltage (AC) 265V
Min Input Voltage (AC) 85V
Nominal Output Voltage 15V
Max Output Power 330W
Current - Output 1 22A
Max Input Voltage 265V
Min Input Voltage 85V
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Output Power 330W
Output Current 22A
Voltage - Input 85V~265VAC
Max Output Current 22A
Output Voltage 15V
Voltage - Isolation 3kV
Efficiency 77%
Approval Agency CE
Number of Outputs 1
Depth 120mm
Max Power Dissipation 300W
Power Rating 330W
Subcategory Power Supply Modules
Additional Feature REMOTE SHUTDOWN
Applications ITE (Commercial)
Type Enclosed
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Adjustable Output, DC Input Capable, PFC, Remote Sense, Universal Input
Size / Dimension 7.48Lx4.72W x 3.62 H 190.0mmx120.0mmx92.0mm
Series JWS (300W)
Published 1999
Operating Temperature -10°C~65°C With Derating
Physical
Weight 1.9kg
Number of Pins 14
Mounting Type Chassis Mount
Mount Chassis Mount, Panel
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 2 months ago)
Factory Lead Time 15 Weeks
