HWS600-12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 12V 600W
PDF
/
Buying Options
Total Price: USD $546.44
Unit Price: USD $546.436
≥1 USD $546.436
≥10 USD $531.67312
Inventory: 127
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
Physical
Mount Chassis, Chassis Mount, Panel
Mounting Type Chassis Mount
Number of Pins 7
Weight 907.18474g
Technical
Operating Temperature -10°C~70°C With Derating
Published 2005
Series HWS (600W)
Size / Dimension 6.50Lx3.94W x 3.23 H 165.1mmx100.1mmx82.0mm
Feature Adjustable Output, DC Input Capable, Load Sharing, Remote On/Off, Universal Input
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Enclosed, Conformal Coated
Applications ITE (Commercial)
Power Rating 648W
Max Power Dissipation 600W
Depth 100.08mm
Current Rating 53A
Number of Outputs 1
Approval Agency CE
Efficiency 83%
Voltage - Isolation 3kV
Output Voltage 12V
Max Output Current 53A
Voltage - Input 85V~265VAC
Output Current 53A
Output Power 636W
Min Input Voltage 85V
Max Input Voltage 265V
Current - Output 1 53A
Max Output Power 648W
Nominal Output Voltage 12V
Min Input Voltage (AC) 85V
Max Input Voltage (AC) 265V
Dimensions
Height 82.042mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
