HWS15-48/A
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Converters
Description
AC/DC CONVERTER 48V 15W
PDF
/
Inventory: 3382
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis, Chassis Mount, Panel
Mounting Type Chassis Mount
Number of Pins 5
Weight 179.999996g
Technical
Operating Temperature -10°C~70°C With Derating
Published 2005
Series HWS (15W)
Size / Dimension 3.15Lx1.24W x 3.23 H 80.0mmx31.5mmx82.0mm
Feature Adjustable Output, DC Input Capable, Universal Input
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 6
Type Enclosed
Applications ITE (Commercial)
Power Rating 15W
Max Power Dissipation 15W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Number of Functions 1
Depth 82mm
Current Rating 330mA
Frequency 63Hz
JESD-30 Code R-XXMA-X6
Number of Outputs 1
Approval Agency CE
Efficiency 80%
Voltage - Isolation 3kV
Output Voltage 48V
Max Output Current 330mA
Input Voltage-Nom 100V
Trim/Adjustable Output YES
Voltage - Input 85V~265VAC
Output Current 330mA
Output Power 15W
Current - Output 1 330mA
Dimensions
Height 82.042mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
