BP5729
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP Module, 8 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER 12V 24W
PDF
/
Inventory: 1498
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 12-SIP Module, 8 Leads
Technical
Operating Temperature -25°C~80°C With Derating
Packaging Bulk
Published 2010
Size / Dimension 1.47Lx0.37W x 0.96 H 37.4mmx9.3mmx24.3mm
JESD-609 Code e2
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Enclosed
Terminal Finish Tin/Copper (Sn/Cu)
Applications ITE (Commercial)
Power (Watts) 24W
Subcategory Power Supply Modules
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XSMA-T8
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 90%
Output Voltage 12V
Max Output Current 2A
Voltage - Output 1 12V
Input Voltage-Nom 311V
Trim/Adjustable Output NO
Interface On/Off
Voltage - Input 85V~264VAC
Output Configuration High Side
Fault Protection Over Temperature, Reverse Current
Line Regulation 13mV
Load Regulation 20mV
Compliance
RoHS Status ROHS3 Compliant
