BP5722A12
RoHS
RoHS compliant
RoHS compliantPackage 11-SIP Module, 7 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER 12V 12W
PDF
/
Buying Options
Total Price: USD $15.69
Unit Price: USD $15.68735
≥1 USD $15.68735
≥10 USD $12.87155
≥100 USD $12.4697
≥500 USD $12.0669
≥1000 USD $11.66505
Inventory: 8102
Minimum: 1
-
+
Technical Details
Technical
Min Supply Voltage (AC) 154V
Load Regulation 30mV
Line Regulation 8mV
Max Supply Voltage (AC) 286V
Fault Protection Over Temperature, Over Voltage
Max Input Voltage 286V
Min Input Voltage 154V
Output Power 13W
Output Current 1A
Power Dissipation 13W
Output Configuration Low Side
Voltage - Input 154V~286VAC
Interface On/Off
Trim/Adjustable Output NO
Max Output Current 1.1A
Output Voltage 12V
Efficiency 83%
Qualification Status Not Qualified
Number of Outputs 1
Time@Peak Reflow Temperature-Max (s) 10
Terminal Pitch 2.54mm
Supply Voltage 12V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position SINGLE
Technology HYBRID
Power Rating 13W
Subcategory Power Supply Modules
Power (Watts) 12W
Applications ITE (Commercial)
Terminal Finish TIN COPPER
Type Enclosed
ECCN Code EAR99
Number of Terminations 11
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e2
Size / Dimension 1.28Lx0.37W x 0.85 H 32.5mmx9.5mmx21.5mm
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -25°C~80°C With Derating
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Physical
Number of Pins 11
Package / Case 11-SIP Module, 7 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 19 Weeks
