BP5068-15
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP Module, 7 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER -15V 12W
PDF
/
Buying Options
Total Price: USD $7.21
Unit Price: USD $7.20955
≥1 USD $7.20955
≥10 USD $5.91565
≥100 USD $5.7304
≥500 USD $5.5461
≥1000 USD $5.36085
Inventory: 10606
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Technical
Min Supply Voltage (AC) 85V
Load Regulation 500mV
Line Regulation 200mV
Max Supply Voltage (AC) 115V
Fault Protection Over Temperature, Reverse Current
Output Power 12W
Output Current 800mA
Output Configuration High Side
Voltage - Input 85V~115VAC
Interface On/Off
Trim/Adjustable Output NO
Input Voltage-Nom -141V
Voltage - Output 1 -15V
Max Output Current 2A
Output Voltage 15V
Efficiency 85%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XSMA-T7
Pin Count 12
Time@Peak Reflow Temperature-Max (s) 10
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position SINGLE
Technology HYBRID
Subcategory Power Supply Modules
Power (Watts) 12W
Applications ITE (Commercial)
Terminal Finish Tin/Copper (Sn/Cu)
Type Enclosed
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e2
Size / Dimension 1.36Lx0.44W x 0.85 H 34.5mmx11.3mmx21.5mm
Series BP5068
Published 2008
Packaging Bulk
Operating Temperature -20°C~80°C With Derating
Physical
Package / Case 12-SIP Module, 7 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 15 Weeks
