BP5047A24
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP Module, 6 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER 24V 4W
PDF
/
Buying Options
Total Price: USD $3.69
Unit Price: USD $3.686623
≥1 USD $3.686623
Inventory: 4523
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 19.05mm
Technical
Min Supply Voltage (AC) 176V
Line Regulation 50mV
Max Supply Voltage (AC) 253V
Total Power Output-Max 3.87W
Output Power 3.6W
Output Current 150mA
Voltage - Input 176V~253VAC
Min Supply Voltage 249V
Max Supply Voltage 358V
Trim/Adjustable Output NO
Input Voltage-Nom 311V
Max Output Current 150mA
Output Voltage 24V
Efficiency 78%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XSMA-T6
Pin Count 12
Time@Peak Reflow Temperature-Max (s) 10
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 4W
Subcategory Power Supply Modules
Power (Watts) 4W
Applications ITE (Commercial)
Terminal Finish Tin/Copper (Sn/Cu)
Type Enclosed
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e2
Size / Dimension 1.36Lx0.36W x 0.75 H 34.5mmx9.2mmx19.1mm
Series BP5047
Published 2008
Packaging Bulk
Operating Temperature -20°C~80°C With Derating
Physical
Number of Pins 12
Package / Case 12-SIP Module, 6 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 30 Weeks
