BP5039A
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP Module, 6 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER 24V 5W
PDF
/
Inventory: 8455
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 12-SIP Module, 6 Leads
Number of Pins 6
Technical
Operating Temperature -20°C~80°C With Derating
Packaging Bulk
Published 2006
Series BP5039
Size / Dimension 1.38Lx0.36W x 0.77 H 35.0mmx9.1mmx19.5mm
JESD-609 Code e2
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type Enclosed
Terminal Finish Tin/Copper (Sn/Cu)
Applications ITE (Commercial)
Power (Watts) 5W
Subcategory Power Supply Modules
Max Power Dissipation 5W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) 10
Pin Count 12
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 82%
Output Voltage 24V
Output Type Fixed
Max Output Current 200mA
Input Voltage-Nom 141V
Trim/Adjustable Output NO
Max Supply Voltage 170V
Min Supply Voltage 113V
Voltage - Input 80V~120VAC
Output Current 200mA
Output Power 4.8W
Max Input Voltage 170V
Total Power Output-Max 5.2W
Max Supply Voltage (AC) 120V
Line Regulation 300mV
Load Regulation 250mV
Min Supply Voltage (AC) 80V
Dimensions
Height 19.558mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
