RAC40-15DA
RoHS
RoHS compliant
RoHS compliantPackage 7-DIP Module, 5 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
CONV AC/DC 40W +/-15V OUT DL T/H
PDF
/
Inventory: 2962
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 27.432mm
Technical
Load Regulation ±1%
Line Regulation ±0.5%
Current - Output 2 1.32A
Isolation Voltage 4kV
Nominal Output Voltage -15V
Max Output Power 40W
Output Power 40W
Output Current 1.333A
Voltage - Input 90V~264VAC
Current - Output (Max) 1.33A 1.33A
Max Output Current 1.33A
Output Voltage 15V
Efficiency 83%
Approval Agency CE, cULus
Qualification Status Not Qualified
Number of Outputs 2
Depth 81.3mm
Max Power Dissipation 40W
Power Rating 40W
Subcategory Power Supply Modules
Applications Medical
Type Enclosed
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature OCP, OTP, SCP
Size / Dimension 3.50Lx2.50W x 1.08 H 89.0mmx63.5mmx27.5mm
Series POWERLINE RAC40-A (40W)
Operating Temperature -25°C~70°C With Derating
Physical
Weight 0.618lb 280.32g
Number of Pins 8
Package / Case 7-DIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole
